10 KVA mainline voltage stabilizer: double booster stabilizer online
Boost switching regulator: efficiently convert the input voltage to a higher output voltage
The product series of the boost switching regulators includes synchronous and non-synchronous devices. These devices can meet the needs of applications ranging from a few milliamps to 100A with an efficiency of up to 96% and have a wide input voltage operating range (wide input voltage), Key features such as low quiescent current (low IQ) to help extend battery life and adjustable frequency (with external synchronization to help manage switching noise).
low voltage to the high voltage stabilizer
The online dual boost regulator uses silicon steel sheets with high magnetic permeability to insert into an iron core group. The primary winding calculates the number of turns per volt and the primary and secondary With current, the cross-sectional area of the winding can be calculated (converted to the diameter of the winding).
The primary and secondary should be insulated. After the winding is completed, the power-on experiment shall be carried out, and the insulation dipping and drying treatment shall be done after being qualified.
The boost regulator can minimize switching losses and maintain high efficiency within the specified input voltage range of 16 V to 34 V. The converter's regulated output voltage can vary from 12 V to 34 V, while the output current can be as high as 11.5 A, and the power supply exceeds 200 W.
double booster stabilizer online
The boost regulator reduces losses to achieve very high efficiency through a wider input and output voltage range and high output current. The high-frequency operation also achieves best-in-class power density and transient response. Therefore, these converters are designed for a variety of high-performance applications, including computing, communications, industrial, LED lighting, and battery systems.
The boost regulator uses a variety of advanced power technologies to achieve solutions with high power density, optimized size, and excellent thermal performance(SCIENTEK ELECTRICAL). Our ultra-efficient controllers and integrated converters can help you achieve any design goals.
