Servo motor voltage stabilizer automatically adjusts input and output voltage, with fast response speed, high precision, and high efficiency. In addition, there will be no surge voltage stabilizer for sudden calls after a power failure.
When the voltage is input, the control circuit board will perform sampling, comparison, amplification, and other functions, and the servo motor will immediately rotate so that the position of the carbon brush of the voltage regulator can be changed to comply with the changing voltage(static voltage regulator). In this way, the stability of the output voltage is maintained, and the working principle of compensation is also adopted for the larger capacity.
The constant voltage regulator can adjust the instantaneous voltage. Input transients and spikes have no effect on the output. Sine output waveform. Designed to provide you with comprehensive protection against power-related issues and adjust the power supply to suit the needs of microprocessor-based devices. It effectively regulates voltage changes, suppresses transients, and bridges short-term interruptions/sags.
The voltage stabilizer has an automatic regression circuit, which in turn consists of a sampling transformer, a rectifier circuit, a small-time constant filter circuit, a voltage divider circuit, an operational amplifier, a drive circuit, a relay, and an energy storage circuit. When the input mains is lower than 200V and Shut down or power failure, the brush will automatically return to the position close to 260V on the wire package. When the input mains is higher than 200V, regardless of shutdown or power failure, the brush will stop in the state before shutdown.
industrial servo voltage stabilizer: line voltage stabilizer
As a result of this intelligent automatic return circuit, the problem of large current when starting up is completely solved, and the service life of the voltage stabilizer is prolonged. The core is an AC voltage regulating transformer (auto voltage regulator), a control circuit controls a servo motor, and drives the voltage regulator to automatically adjust the voltage.
