A split type single-axis stabilizer, including a handle and a clamping plate, the clamping plate is detachably fixed on the upper end of the handle through a threaded cap; both sides of the lower end of the handle are provided with strip grooves, and the upper end of the inner cavity of the handle is passed through screws A motor is fixed, the output shaft end of the motor is connected with a turntable, and the left end of the turntable is provided with a first convex edge.
The middle of the right end surface of the turntable is provided with a cross key, the right side of the upper end of the handle is sleeved with a threaded ferrule, and the end of the threaded ferrule away from the handle is provided with a second convex edge; the threaded pin is clamped on the outer circumference of the threaded ferrule; The middle part of the left end surface of the clamping plate is provided with 4 vertical plates, and the 4 vertical plates are arranged side by side in two to form a cross keyway compatible with the cross key; the front and rear ends of the clamping plate are symmetrically provided with telescopic For the splint, the inner side of the right end of the telescopic splint is provided with a convex plate, and the left end of the telescopic splint is provided with a gap; the utility model has the advantages of compact structure, convenient carrying, convenient use, and strong sensitivity.
The split AC stabilizer has a split stabilizer with an optimized spring rate. It consists of a first stabilizer part, a second stabilizer part, and a reversible motor(ac voltage stabilizer characteristics & installation environmental condit). They are all arranged on a common shaft. The reversible motor is composed of an outer rotating part and an inner rotating part, which work together with a bearing cover and a flange cover to form two or more opposing pressure chambers and two or more opposing suction Cavity, and the pressure cavity and the suction cavity are respectively connected by a radial connecting channel.
Relay type Automatic Voltage Regulator
Or the force-transmitting fitting connection between the inner rotating part and a connecting journal of the second stabilizer part consists of an engaging part and a mating part, and both of them are hot-fitted, wherein the radial The connecting channel is arranged between the inner rotating part and the second stabilizer part in a gapless mating connecting part.
